CHASSIS ROBÔ 4WD EM ALUMÍNIO COM 4 RODAS MECANUM E MOTORES

: ROB05061
24,50 €
preço com IVA incluído

Plataforma robótica para montagem que já conta com quatro rodas omnidirecionais e quatro motores, assim como duas placas de alumínio, todos os parafusos e porcas necessárias. Uma excelente opção se desejas construir o teu próprio robot!

Quantidade

Se tiver alguma dúvida neste produto não hesite em contactar-nos.

*Atenção: as imagens são meramente ilustrativas.

4WD Mecanum Wheel Robot Cart Chassis Kit

The cart chassis of this product is easy to assemble. This link is a loose part, you need to assemble it by yourself. Has a strong scalability, can complete a variety of functions intelligent trolley, to meet most of the sensors on the market fixed. Customers can DIY according to their own needs with the development board, their own formation of trajectory, obstacle avoidance, bluetooth and other functions of the trolley.

  1. Aluminum Chassis:  Aluminum alloy material maintains the advantages of lightweight but also has high strength, and the chassis adopts removable design, which is convenient for users to modify and expand by themselves.

  2. Plenty of Expansion Holes: A large number of holes can be installed with the motherboard and various sensors, camera modules, robotic arms and so on. Mechanical arm, etc., the bottom of the car body is equipped with battery mounting position, which is convenient for users to expand by themselves. Battery mounting position is provided on the bottom of the car body, which is convenient for users to expand by themselves.

  3. Mecanum Wheels with DC Geared Motor: Mecanum Wheel rollers can be moved forward or backward like a traditional wheel, allowing for sideways movement, spinning wheels. The front and rear axles are in opposite directions and support rotation at 45°, allowing for flexible movement even in small spaces to reach a destination.

DC Geared Motor

  1. Working voltage:DC3-6V

  2. Rated voltage:DC4.5V No-load current:?80mA

  3. No-load speed:about 200rpm measured 180rpm Gear ratio:1:48



Includes

Single layer chassis kit

  1. 1x Aluminum alloy chassis A

  2. 4x DC Geared Motor

  3. 2x Mecanum wheel A

  4. 2x Mecanum wheel B

  5. 8x M3*30MM screws

  6. 8x M3 nickel-plated

  7. 4x Coupling

  8. 4x M2.3*16MM screw



Double chassis kit

  1. 1x Aluminum alloy chassis A

  2. 1x Aluminum Chassis B

  3. 2x McNamee wheel A

  4. 2x McNamee wheel B

  5. 4x DC gear motor

  6. 6x Double pass copper pole

  7. 4x Coupling

  8. 8x M3*30MM screws

  9. 12x M3*6MM screw

  10. 4x M2.3*16MM screws

  11. 8x M3 nickel-plated

ROB05061
