Lidar XT-S1 (ToF) Sensor de Distancia Laser (0.3-30m, UART/I2C/IO) - DFRobot SEN0585

: SEN03074
65,00 €
preço com IVA incluído

Este é um sensor de distância laser, para além de ser bastante compacto (44x16x24mm) e leve (9g), tem também um consumo bastante reduzido de energia (inferior a 0.5W). Perfeito para ambientes interiores devido ao seu pequeno tamanho e também para ambientes exteriores pois consegue aguentar iluminações intensas e tem um alcance de 30m que consegue fornecer medições estáveis e precisas.

Nota: Não olhes diretamente para o radar laser com os olhos enquanto o utilizas!

Quantidade
Últimos artigos em stock

DESCRIÇÃO EM PORTUGUÊS BREVEMENTE DISPONÍVEL

Se tiver alguma dúvida neste produto não hesite em contactar-nos.

*Atenção: as imagens são meramente ilustrativas.

Introduction

This is a compact single-point laser radar based on the Time-of-Flight (ToF) principle. With a lightweight design of only 9 grams, it is incredibly convenient to install. Thanks to its low power consumption, which is less than 0.5W, it is well-suited for battery-powered or low-power demanding scenarios.

Overview of XT-S1 ToF Single-Point Ranging LiDAR Sensor (0.3-30m)

This laser radar offers compatibility with both indoor and outdoor environments with intense lighting conditions of up to 100klux, enabling reliable operation in various bright settings. With a measurement range of up to 30 meters, it provides stable, precise, and highly sensitive distance measurements.

Size of XT-S1 ToF Single-Point Ranging LiDAR Sensor (0.3-30m)

The application potential of this laser radar is extensive. In the field of unmanned aerial vehicles (UAVs), it can be used for altitude control, ensuring the drone maintains a stable flying height. In robotics, it proves valuable for collision avoidance, helping robots detect and navigate around obstacles. In the realm of smart homes, it can be employed for environmental perception and tracking, enabling intelligent control of home devices based on human position and movement.

Note: Please don't directly look into the laser radar with your eyes while using it!



Features

  1. Compact size

  2. Lightweight

  3. Measurement range of up to 30m indoors and outdoors



Applications

  1. Altitude control
  2. Collision avoidance
  3. Smart homes

Applications of XT-S1 ToF Single-Point Ranging LiDAR Sensor (0.3-30m)



Specification

  1. Measurement range: 0.3~30m (90% reflectivity indoors and outdoors)

  2. Measurement accuracy: 30~250cm @ ±5cm, 250~3000cm @ ±2%cm

  3. Operating voltage: 4.8~5.2V

  4. Power consumption: ＜100mA @ 5V

  5. Communication interfaces: UART/I2C/IO

  6. Wavelength: 940nm

  7. Resolution: 1cm

  8. Measurement frequency: Maximum 50Hz

  9. Ambient light immunity: 100klux

  10. Emitter angle: Half-angle of 2°

  11. Receiver angle: Half-angle of 1°

  12. Operating temperature: 10°C~60°C

  13. Storage temperature: -20°C~70°C

  14. Weight: 9g



Documents



Shipping List

  1. XT-S1 ToF Single-Point Ranging LiDAR Sensor(0.3-30m) x1

  2. 6-pin DuPont cable x1
