Módulo Driver de Motores 4 canais L293D

DESCRIÇÃO EM PORTUGUÊS BREVEMENTE DISPONÍVEL

Se tiver alguma dúvida neste produto não hesite em contactar-nos.

*Atenção: as imagens são meramente ilustrativas.

Key Features:

• Two 5V Servo Motor Ports: Enjoy jitter-free connectivity with high-resolution, high-precision timers tailored for Arduino, ensuring your motor control is seamless and reliable.
• Multi-Motor Capability: Effortlessly manage up to four bidirectional DC motors with four PWM speeds, each boasting an incredible 0.5% resolution. Experience unparalleled control over your motor functions.
• Stepper Motor Flexibility: Seamlessly control up to two stepper motors with options for positive and negative control, single/double step control, interleaved or microstep control, and even precise rotary angle manipulation.
• Robust L293D Chip: Our module is powered by the L293D chip, offering the ability to handle up to 0.6A (with a maximum of 1.2A) current per bridge. Benefit from thermal shutdown protection and a versatile voltage range of 4.5V to 36V.
• Power-Up Assurance: The integrated pull-down resistor guarantees that your motor remains stationary during power-up, preventing any unexpected movements.
• User-Friendly Design: Module features large terminal terminals designed to simplify wiring, accommodating wire sizes ranging from 10 to 22AWG. The addition of an Arduino reset button further enhances convenience.
• Dual Power Terminals: With two external power terminals, ensure a clear separation between logic and motor drive power, enhancing overall safety and efficiency.
• Board Compatibility: Engineered to seamlessly integrate with Mega, Diecimila, and Duemilanove boards, the module provides universal compatibility for your convenience.
