Módulo Acelerómetro i2c 3~5Vdc MMA7660

Se tiver alguma dúvida neste produto não hesite em contactar-nos.

*Atenção: as imagens são meramente ilustrativas.

Specifications

MMA7660 acceleration module

1. Triaxial accelerometer module MMA7660 acceleration module digital module
2. The module is compatible with the 3-5V level
3. Means of communication IIC
4. Power supply 3-5V
5. PCB size: 21mm multiplied by 14mm
6. Module pin VCC GND SCL SDA INT pin

The MMA7660FC ± 1.5 g 3-axis digital output accelerometer taking into account that this is a very low power consumption, low profile sensor has a capacitive MEMS low-pass filter, compensation for 0g offset and gain errors, and converted to 6-bit per second user-configurable digital sample value, the device can be used for sensor data changes, product positioning, and gesture detection through an interrupt pin (INT) the device is mounted in a small 3mm x 3mm x0.9mm DFN packaging.
