WIFI232 Eval Kit

: COM02035
€28.90
Tax included

WIFI232 Eval Kit is a WiFi to UART Evaluation Kit, including a convertor module WIFI232-B, and a mother board WIFI501 for testing/evaluating.

Quantity

If you have any questions on this product please feel free to contact us.

*Disclaimer: The images are merely illustrative.

Overview

WIFI232 Eval Kit is a WiFi to UART Evaluation Kit, including a convertor module WIFI232-B, and a mother board WIFI501 for testing/evaluating.

Features

  • What's onboard: USB to UART connector, Reload button, LED indicators, Reset button, RJ45 Ethernet connector, RS485 connector
  • Indicators: Power, Ready, Link, RXD, TXD, PWM
  • Powered from DC 5V
  • Provides TCP/IP host computer examples (VB / Delphi / Borland C++)

How to Use

  • Reload button: power up, press and hold it (>=3s) then release, to restore the module to its factory settings immediately
  • Ready indicator: lights up when the WiFi module starts up successfully
  • Link indicator: works with the WIFI232 series modules, lights up when network connection detected
  • PWM indicator: works with the WIFI-LPT100 module, the indicator brightness will be changed while PWM output was enabled

Photos


Downloads

Development resources: demo codes, schematic, datasheets, etc.
Wiki: www.waveshare.com/wiki/WIFI232_Eval_Kit

Weight: 0.198 kg

Contents:

  • WIFI232-B × 1
  • WIFI501 × 1
  • External antenna × 1
  • USB type A plug to mini-B plug cable x 1
  • 5V power adapter × 1
