- New
![](https://www.botnroll.com/21917-medium_default/oscilloscope-100mhz-2-channels-utd2102cl.jpg)
The UNI-T UTD2102CL+ is a high-performance benchtop digital oscilloscope with two analog input channels, a bandwidth of 100 MHz and a sampling rate of 500 MS/s. It has a 7-inch TFT color screen and offers advanced functions such as automatic measurement of 34 signal parameters, mathematical operations between signals, and storage via USB. The device is easy to operate, ideal for users looking for precision and simplicity in electronic measurements.
If you have any questions on this product please feel free to contact us.
*Disclaimer: The images are merely illustrative.
Feature |
Specification |
---|---|
Model Number |
UTD2102CL+ |
Bandwidth |
100MHz |
Channels |
2 Analog |
Real-Time Sample Rate |
500MSa/S |
Rise Time |
≤3.5ns |
Memory Depth |
64kpts |
Waveform capture rate |
5,000wfms/s |
Time-base scale |
2ns/div-50s/div |
Input impedance |
(1M0± 2%)//(18pF± 3 pF) |
Waveform Generator |
No |
Display |
7-inch LCD |
Touchscreen |
No |
Warranty |
3 years |
Shipping Dimensions (W x H x L) |
306mmx 138mmx 124mm |
Shipping Weight |
3 kg |
Documents |
English download guide, multi-language safety manual, calibration report (COC) |
Included Accessories |
Power cord, USB2.0 printing cable, UT-P04 Passive probe x 2(lx,10x switchable,100 |
