- DISCONTINUED
DC & AC voltage/current, Resistance, capacitance, diode, continuity
Specifications:
Basic Functions
DC Voltage (V) min range 200mV
max range 1000V
best accuracy ±0.5%
AC Voltage (V) min range 2V
max range 750V
best accuracy ±0.8%
DC Current (A) min range 20mA
max range 20A
best accuracy ±0.8%
AC Current (A) min range 20mA
max range 20A
best accuracy ±1%
Resistance (Ohms) min range 200Ω
max range 200MΩ
best accuracy 0.80%
Capacitance (F) min range 20nF
max range 100uF
Temperature (°C) min range -40°C
max range 1000°C
Temperature (°F) min range -40°F
max range 1832°F
Frequency (Hz) min range 2kHz
max range 20kHz
Special Functions
