JGB37-3530 Small DC Gear Motor 12V 20RPM
JGB37-3530 Small DC Gear Motor 12V 20RPM
If you have any questions on this product please feel free to contact us.
*Disclaimer: The images are merely illustrative.
Specifications
General |
|
---|---|
Brand |
Aslong |
Manufacturer model/SKU |
JGB37-3530 |
Features |
Motor |
General physical appearance |
|
Main color |
Gray/silver |
Weight [g] |
200 |
Dimension X [mm] |
37 |
Dimension Y [mm] |
37 |
Dimension Z [mm] |
65 |
Mounting options |
Screw thread |
Thread size |
M3 |
General electrical properties |
|
Maximum supply voltage [V DC] |
15 |
Indication average current consumption [mA] |
200 |
Motor |
|
Motor type |
DC-motor |
Maximum holding torque [N.m] |
7.3 |
Phase resistance [Ω] |
2 |
Maximum speed [RPM] |
20 |
Transmission |
506:1 |
Gear material |
Metal |
Shaft |
|
Shaft type |
D-shape |
Shaft diameter [mm] |
6.0 |
Shaft length [mm] |
15 |
Connectors |
|
Motor connector(s) |
Disconnect male |
Connector/pin width [mm] |
2.8 |
Package contents |
|
Package contents |
1x DC transmission motor |
